A50P250 Gould Shawmut AmpTrap type 4 A50P250-4 Mersen (lower I2t)
$60.00
Skip to product information
- Same day service is possible if we recieve motor by 7 AM,
A50P250 Gould Shawmut AmpTrap type 4 A50P250-4 Mersen (lower I2t)
$60.00
Taxes included.
Shipping calculated at checkout.
- High Speed Fuse Amp-Trap® A50P 500VAC 450VDC 250A Blade
- A50P250 Gould Shawmut AmpTrap type 4
- Mersen A50P250-4
- Mersen A50P2504
- AmpTrap type 4
A50P250-4 | A50P250 Gould Shawmut AmpTrap type 4
Series: Amp-Trap® A50P 500VAC 450VDC
High Speed Fuse Amp-Trap® A50P 500VAC 450VDC 250A Blade
A50P Amp-Trap® Form 101 high speed fuses were developed for DC drives, uninterruptable power supplies and similar applications requiring better protection (lower I2t) and superior reliability. The A50P is typically used for replacement.
Technical Specifications
| Item number | A50P250-4 |
| Description | High Speed Fuse Amp-Trap® A50P 500VAC 450VDC 250A Blade |
| EAN/UPC Code | 782001946180 |
| Rated voltage AC UL | 500 V |
| Rated voltage DC UL | 450 V |
| Frequency (Hz) | 50/60 Hz |
| Ampere Rating | 250 A |
| ROHS Compliant | Yes |
| AC or DC | AC/DC |
| Speed/Characteristic | High Speed |
| Mounting | Bolted |
| AC Max I.R./Breaking Capacity: I1 | 52 kA |
| Connection/Terminal Material | Tin-Plated Brass |
| Connection/Terminal Type | Blade |
| Product Diameter | 38.1 mm |
| Product Length | 110.2 mm |
| Sell Pack Quantity | 1EA |
| Sell Pack Weight | |
| Sell Pack Width | 111.3 mm |
| Sell Pack Length | 196.8 mm |
| Sell Pack Height | 76.2 mm |
| Product group | High-Speed and Semiconductor protection fuses |
| Body/Insulating Material | GMG |
| Product Weight | 0.3084 kg |
