- Manufacturer Part Number: BNS 819-FR-60-101
- Manufacturer Alternative MPN ; Order Code: BNS0013
- Manufacturer Id Nr. BNS819-FR-60-101
BNS0013 _ BNS 819-FR-60-101
Mechanical single position limit switches
Dimension : 74 x 28 x 61 mm
Housing material : Aluminum, Anodized
Number of switching positions : 1x Roller
Version : Snap contact : Operating principle : 1. Switch position: Mechanical
Functional safety
B10d (EN ISO 13849-1) BSE 30.0: 30 mil. switching cycles
Material
Housing material Aluminium, Anodized
Housing material, surface protection Anodized
Material contacts 1. Switch position: Silver, gold
plated
Plunger material 1. Switch position: 1.4034
stainless steel
Mechanical data
Approach direction lateral or at right angles to
mounting surface
Approach speed 1. Switch position: 60 m/min
Dimension 74 x 28 x 61 mm
Distance cam - reference edge 1. Switch position: 4.50...5.00 mm
Flange, feed-through None
Installation any
Life expectancy mechanical 1. Switch position: 30 mil.
switching operations
Number of switching positions Roller Mechanical
Plunger spacing 1st switch position 14 mm
Plunger style 1st switch position: Roller
1st switch position: Roller
Switch actuation force 1. Switch position: 20 N
Switching element 1. Switch position: BSE 30.0
B10d (EN ISO 13849-1) BSE 30.0: 30 mil. switching cycles
Material
Housing material Aluminium, Anodized
Housing material, surface protection Anodized
Material contacts 1. Switch position: Silver, gold
plated
Plunger material 1. Switch position: 1.4034
stainless steel
Mechanical data
Approach direction lateral or at right angles to
mounting surface
Approach speed 1. Switch position: 60 m/min
Dimension 74 x 28 x 61 mm
Distance cam - reference edge 1. Switch position: 4.50...5.00 mm
Flange, feed-through None
Installation any
Life expectancy mechanical 1. Switch position: 30 mil.
switching operations
Number of switching positions Roller Mechanical
Plunger spacing 1st switch position 14 mm
Plunger style 1st switch position: Roller
1st switch position: Roller
Switch actuation force 1. Switch position: 20 N
Switching element 1. Switch position: BSE 30.0
Approval/Conformity CE
UKCA
CCC
WEEE
Basic standard IEC 60947-5-2
DIN switch DIN 43693
Operating principle 1. Switch position: Mechanical
Version Snap contact
Display/Operation
Function indicator 1. Switch position: None
Electrical connection
Connection type 1. Switch position: Screw terminal
Electrical data
Continuous current 1. Switch position: 6 A
Rated operating voltage Ue 1. Switch position: 250 V AC
Switching function mechanical Double-interrupting
galvanically isolated
One NO and one NC
Dual changeover
Switching rate 1. Switch position: 300/min
Environmental conditions
Ambient temperature -5...85 °C
IP rating IP67
UKCA
CCC
WEEE
Basic standard IEC 60947-5-2
DIN switch DIN 43693
Operating principle 1. Switch position: Mechanical
Version Snap contact
Display/Operation
Function indicator 1. Switch position: None
Electrical connection
Connection type 1. Switch position: Screw terminal
Electrical data
Continuous current 1. Switch position: 6 A
Rated operating voltage Ue 1. Switch position: 250 V AC
Switching function mechanical Double-interrupting
galvanically isolated
One NO and one NC
Dual changeover
Switching rate 1. Switch position: 300/min
Environmental conditions
Ambient temperature -5...85 °C
IP rating IP67
