Baumer CANOPEN GXMMW.A205PA2, Shaft 10mm Clamping, Singleturn 13bit, Multiturn 16bit

$918.00 $1,080.00
Taxes included. Shipping calculated at checkout.

You Are Welcome to use your OWN COURIER Account for Shipping.

Please Choose: In Store PICKUP option (instead of Ship)  at Checkout/Payment Screen.

You Pay zero Shipping & You can Arrrange pickup via your DHL/ FEDEX/ UPS  account.

  • Dispatch Lead time = Ready Stock - Collect (In-person pickup) From Store Same day - 3~4 Hours After Cleared Payment.
  • Warranty = One-year limited seller warranty
Download Product Datasheet
  • Manufacturer Part Number = GXMMWA205PA2
  • Manufacturer MPN = GXMMW.A205PA2 | 11032557
  • Encoder Type = Absolute Encoder
  • Supply voltage = 11-30vDC

  • ID. NR. = GXMMW.A205PA2
  • indent Nr. = GXMMW A205PA2

  • Alternative Part Numbers | Compatible Parts = GXMMW.A2O5PA2 | 110 32 557
  • Typographic Errors in MPN | Mistakenly Known as = GXMW.A205PA2
  • Manufacturer Part Number (MPN) = GXMMWA205PA2
View Manufacturer Product Page

Ready Stock GXMM Baumer GXMMWA205PA2 | ABSOLUTE ENCODER, MULTITURN, 10MM SOLID SHAFT (CLAMPING FLANGE), 10-30VDC, M12 CONNECTOR, IP65
Brand: Baumer | MPN: GXMMW.A205PA2 | 11032557  | Steps per revolution ≤8192 / 13 bit
Number of revolutions ≤65536 / 16 bit

GXMMW
Solid shaft with clamping or synchro flange
Encoder multiturn / bus cover
Optical sensing method
Resolution: singleturn 13 bit, multiturn 16 bit
Clamping flange
Interface: Can Open
Code continuity check optional by bus
Maximum resistant against magnetic fields

Resolution: singleturn 13 bit, multiturn 16 bit

Technical data - mechanical design
Size (flange) ø58 mm
Shaft type ø10 mm solid shaft (clamping flange)
Protection DIN EN 60529 IP 54 (without shaft seal),
IP 65 (with shaft seal)


Operating speed ≤10000 rpm (mechanical) | ≤6000 rpm (electric)
Starting acceleration ≤1000 U/s² |  Starting torque ≤0.015 Nm (+25 °C, IP 54)  ≤0.03 Nm (+25 °C, IP 65)
Rotor moment of inertia 20 gcm² | Admitted shaft load ≤20 N axial ≤40 N radial
Materials Housing: steel
Flange: aluminium
Bus cover: zinc die-cast
Operating temperature -25...+85 °C
Relative humidity 95 % non-condensing
Resistance DIN EN 60068-2-6
Vibration 10 g, 16-2000 Hz
DIN EN 60068-2-27
Shock 200 g, 6 ms
Weight approx. 650 g
Connection Bus cover

Voltage supply 10...30 VDC
Reverse polarity protection Yes
Consumption w/o load ≤100 mA (24 VDC)
Initializing time typ. 250 ms after power on
Interfaces : CANopen®
Function Multiturn
Device adress Rotary switch in bus cover
(type-specific)
Steps per revolution ≤8192 / 13 bit
Number of revolutions ≤65536 / 16 bit
Absolute accuracy ±0.025 °
Sensing method Optical
Code Binary
Code sequence CW/CCW programmable
Incremental output 2048 pulses A90°B (optional)
Interference immunity DIN EN 61000-6-2
Emitted interference DIN EN 61000-6-4
Programmable parameters : Steps per revolution
Number of revolutions | Preset | Scaling | Rotating direction

Diagnostic functions Position or parameter error
Multiturn sensing
Status indicator DUO-LED integrated in bus cover
Approval UL approval / E63076

Mechanical Design Features of this Encoder:

  • Absolute Encoder Mechanical Design = Solid shaft, face mount flange
  • Absolute Encoder Construction size (flange) = Ø 58 mm

Design data for Selection | design of Shaft Coupling for this encoder

  • Absolute Encoder Shaft diameter = 10 mm

Encoder Communication Protocall & interface

  • Absolute Encoder Communication interface = CANopen

Encoder Performance Parameters

  • Absolute Encoder - Singleturn or multiturn version = Multiturn
  • Absolute Encoder - Number of steps per revolution = 8192 (13 bit)
  • Absolute Encoder Number of revolutions = 65536 (16 bit)

Absolute Encoder Programmable/configurable = YES : Programmable/configurable

Encoder's Electrical Signal output connection - for Wiring to Upper Level Control PLC| CNC\ DRIVE

  • Direction of Connection = Radial
  • Connection Type Detail = Bus Cover

How Encoder body is Mouted ? Mouting Flange Design Data:
