Baumer KTD 3-4 A 4 L Y 4 | KTD3-4 A4 | KTD 3-4 ... Rated Voltage(V) 40, Square Flange
$1,880.00
Skip to product information
Baumer KTD 3-4 A 4 L Y 4, M :11058605 C: 100421465-001; referenced to 1000 rpm
- Ready Stock | Ship Worldwide
- Rush Orders can be Collected from our Store after 4 Hours of Order Confirmation
- We ship Same day if Order is confirmed before 2 PM on Weekdays
Baumer KTD 3-4 A 4 L Y 4 | KTD3-4 A4 | KTD 3-4 ... Rated Voltage(V) 40, Square Flange
$1,880.00
Taxes included.
Shipping calculated at checkout.
Condition: New surplus / new old stock. SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: KTD 3-4 A4 L Y4
- Encoder Type: Tacho Generator
- Supply voltage No Power Supply Needed
- Encoder ID. NR.KTD 3-... A 4, KTD3-4A4
- Encoder SIgnal | | | |
- Product Condition Opened original packaging:
Authorization status : Independent reseller
Manufacturer warranty status : Not represented as included
SpareFaber warranty : One-year limited seller warranty
Packaging condition :
Baumer KTD 3-4 A 4 L Y 4, M :11058605 C: 100421465-001; referenced to 1000 rpm
DC tachogenerator.KTD 3-... A 4;
Shaft dia 15mm
Installation and Operating Instructions
Qualities:
- High reaction rate
- Large speed range
- Recognition of rotation direction
- Small percent ripple
- No power supply
======
Type: KTD 3-4 ... Rated Voltage(V) 40
Rated Current : 10
Max Current 80mA
Upper Speed Limit ; 4000rpm
Armature Resistance: 220Ohm
Weight A4: Rotor ; 360 gram | housing 570 Gram.
=========
Mechanical data:
Housing light-alloy metal, unpainted
Design style A4
Protective class IP 54 according to DIN 40 050, IEC 529
Bore diameter KTD 3-... A 4 d 14 mm, 15 mm ( standard ) ( 10 - 16 mm possible )
KTD 3-... A 4 Y36d 14 mm ( standard ) ( 10 - 16 mm possible )
Mass moment of inertia J KTD 3-1 to KTD 3-3: 600 gcm²
KTD 3-4 to KTD 3-6: 910 gcm²
Polarity dependent on rotation direction
Number of pole pair 2 = 4-poles
Number of grooves, segments 29
Grooves frequency fN = 29 / 30 * n
Reversing error ≤ ± 0,1 %
Residual ripple ≤ 0,4 %
Linearity error ≤ 0,15 %
Regulation range lower limit nR 0 rpm
Temperature drift ( - 10 °C to + 100 °C ) ± 0,1 % / 10 K
Type of connection terminal box, 2-poles
Isolation class B
Carbon brushes 4 pieces AG 3 x 4 x 12
Carbon brushes life approx. 20.000 hours of operation
Maintenance after 10.000 hours in service
Type: KTD3-4 A4, V DC : 40v; a= 40, b=43.5, c=52.5, d=5-0.012/-0.042
Out: +/- 40vdc, In=10Ma
Encoder Type:
Salient | Special features of Encoder:
Encoder mechanical Design
- Increental Encoder Mechanical Design
- Incremental Encoder Construction size (flange)
- Incremental Encoder Shaft diameter
Encoder Signal Interface | Communication
- Incremental Encoder Communication Interface detail
Performance Data:
Incremental encoder PPR | Impulse | Pulses per revolution
- incremental Encoder Range of pulses per revolution
- Signal Details:
Connection Details of encoder
- Connection type (Detail)
- Direction of connection
Mounting Arrangement for Encoder Body
- Check Datasheet or Contact us
- Manufacturer Alternative MPNKTD 3-4 A 4 L Y 4
- Manufacturer indent Nr.KTD3-4A4LY4
- 1 Manufacturer Part Number (MPN) KTD 3-4 A4 L Y4
- Alternative ways of identifying | Part Numbers | Compatible Parts
- Typographic Errors in MPN | Mistakenly Known as
Brand, Condition & Warranty Disclosure
We are Independent Reseller for this Brand - Not Authorised by manufacturer
EMERGENCY BREAKDOWN ? Need it Right away ( After Office hours?) .. No Problem | Can be arranged. Send us a Message.
