Cylindrical miniature version Order Code:  BES018L, BES5163005-FOX-PU-05, 3wire, body Ø 5 x 35.5 mm, flush mounting, Range 0.8 mm, PNP normally open (NO), 3meter cable

Display/Operation
Function indicator no
Power indicator no
Electrical connection
Cable diameter D 3.10 mm
Cable length L 5 m
Conductor cross-section 0.14 mm²
Connection type Cable, 5.00 m, PUR
Number of conductors 3
Polarity reversal protected yes
Protection against device mix-ups no
Short-circuit protection no
Electrical data
Load capacitance max. at Ue 1 µF
Min. operating current Im 0 mA
No-load current Io max., damped 15 mA
No-load current Io max., undamped 12 mA
Operating voltage Ub 10...30 VDC
Output resistance Ra 4.7 kOhm + D
Rated insulation voltage Ui 75 V DC
Rated operating current Ie 200 mA
Rated operating voltage Ue DC 24 V
Rated short circuit current 100 A
Ready delay tv max. 10 ms
Residual current Ir max. 80 µA
Ripple max. (% of Ue) 15 %
Switching frequency 2000 Hz
Utilization category DC -13
Voltage drop static max. 1.5 V
Environmental conditions
Ambient temperature -25...70 °C
Contamination scale 3
EN 60068-2-27, Shock Half-sinus, 30 g , 11 ms
EN 60068-2-6, Vibration 55 Hz, amplitude 1 mm, 3x30 min
IP rating IP67
Functional safety
MTTF (40 °C) 595 a
Interface
Switching output PNP normally open (NO
Material
Housing material Stainless steel
Material jacket PUR
Material sensing surface PBT
Mechanical data
Dimension Ø 5 x 35.5 mm
Installation for flush mounting
Mounting length 30.50 mm
Size M5x0.5
Tightening torque 0.5 Nm
Range/Distance
Assured operating distance Sa 0.65 mm
Hysteresis H max. (% of Sr) 15.0 %
Rated operating distance Sn 0.8 mm
Real switching distance sr 0.8 mm
Repeat accuracy max. (% of Sr) 5.0 %
Temperature drift max. (% of Sr) 10 %
Tolerance Sr ±10 %
