DATALOGIC S50-ML-2-B01-NN 952021820 NPN NONC, LO DO, 16 Meter Range
$290.00
Skip to product information
- Ready Stock | Ship Worldwide
- Rush Orders can be Collected from our Store after 4 Hours of Order Confirmation
- We ship Same day if Order is confirmed before 2 PM on Weekdays
DATALOGIC S50-ML-2-B01-NN 952021820 NPN NONC, LO DO, 16 Meter Range
$290.00
Taxes included.
Shipping calculated at checkout.
SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: S50-ML-2-B01-NN
- Manufacturer Alternative MPN ; 952021820
- Manufacturer Id Nr. S50ML-2-B01-NN
Datasensor - S50-ML-2-B01-NN PHOTOELECTRIC SENSOR, RETROREFLECTIVE, M18, 16M RANGE, NPN LO DO, 2M CABLE, LASER
| Operating distance: |
0.1 ... 16 m (axial optics) |
| Power supply: | 10..30 Vdc |
| Ripple: | ≤2 Vpp |
| Consumption: | <35 mA |
| Light emission: | red Laser 650 nm |
| Resolution: | 9 mm max. over 1 m |
| Setting: | sensitivity trimmer |
| Indicators: | yellow OUTPUT LED green POWER ON LED |
| Output type: | NPN, NO and NC |
| Output current: | ≤ 100 mA |
| Saturation voltage: | ≤ 2V |
| Response time: | 333 μs |
| Switching frequency: | 1.5 kHz |
| Operating mode: |
dark on NO/light on NC |
| Connection: |
2 m Ø 4 mm cable |
| Electrical protection: | class 2 |
| Mechanical protection: IP67 | |
| Housing material: | PBT |
| Lens material: | PMMA/ glass |
| Weight | 25 g max. |
| Operating temperature: -10... +50°C | |
| Storage temperature: | -25 .. +70°C |
- Dimensions:
-
The tubular S50 series is a wide photoelectric sensor line offering through beam, proximity and retroreflex polarized optic functions, available with both LED and laser emission models, radial and axial optics, 2m cable or M12 4-pole connection in plastic housing.
-
Available in DC version offering excellent solutions for all industrial applications, presenting a flat plastic housing with 2 fixing holes to guarantee excellent mounting flexibility.
-
Wide range: suitable for all the industrial applications
-
Laser models: high detection repeatability for a precise reading
-
Cable or M12 4-pole connection: flexible connection to meet customer applications
-
Axial or radial optics: adaptability to the mechanical part of the plant
-
This product series has been developed to satisfy to requirements of the following reference applications: Automatic machines, Packaging lines, Transportation lines, Ceramics working machines, Automatic warehouses
- Product Condition New in Factory Sealed Packet:
Authorization status : Independent reseller
Manufacturer warranty status : Not represented as included
SpareFaber warranty : One-year limited seller warranty
Packaging condition :
- Manufacturer indent Nr.S50ML2-B01-NN
- Alternative ways of identifying | Part Numbers | Compatible Parts
- Typographic Errors in MPN | Mistakenly Known as
EMERGENCY BREAKDOWN ? Need it Right away ( After Office hours?) .. No Problem | Can be arranged. Send us a Message.
