HEIDENHAIN ECN 113 Singleturn EnDat01 Encoder ECN113204827S17-58, 25MM Hollow
$1,980.00
Taxes included.
Shipping calculated at checkout.
- Dispatch Lead time = Same day ship if paid before 2 PM Local time
- Warranty = One-year limited seller warranty
- Manufacturer Part Number = ECN113 2048 27S17-58 R 0.00 .. 42B30A 64 01 .. .. D EnDat01
- Manufacturer MPN = Flange socket M23, male, 17-pin
- Encoder Type = Absolute Encoder
- Supply voltage = 3.6 V to 14 V
- ID. NR. = 528 100-53
- indent Nr. = ECN 113 2048 27S17-58
- Alternative Part Numbers | Compatible Parts =
- Typographic Errors in MPN | Mistakenly Known as =
- Manufacturer Part Number (MPN) = ECN113 2048 27S17-58 R 0.00 .. 42B30A 64 01 .. .. D EnDat01
Ready Stock | HEIDENHAIN ECN 113 2048 27S17-58 Id.Nr. 528 100-53 EnDat01 5V+-5% Flange socket M23, male, 17-pin
ECN 113
Singleturn rotary encoder with integral bearing ECN113 2048 27S17-58 R 0.00 .. 42B30A 64 01 .. .. D EnDat01
ID number 528 100-53
Positions per revolution 8192
Data interface EnDat01
Output code Binary
Line count 2048
Output signal ~1Vpp
Cutoff frequency (-3 dB) 400.00 kHz
Power supply 5 V
Coupling version : Stator coupling for plane surface (hole circle Ø 96 mm)
Type of Coupling 30A
Shaft Hollow through shaft with eccentric clamping, diameter 25 mm
Type of Shaft 42B
Protection rating IP64 (EN60529)
Operating temperature -40/+100 °C
Electrical connection Flange socket M23, male, 17-pin
Pin configuration D288678
Connecting direction radial
Operating InstructionsMechanical Design Features of this Encoder:
- Absolute Encoder Mechanical Design = 06 stator coupling for axial mounting (heidenhain)
- Absolute Encoder Construction size (flange) = Ø 58 mm
Design data for Selection | design of Shaft Coupling for this encoder
- Absolute Encoder Shaft diameter = 65B tapered shaft (heidenhain)
Encoder Communication Protocall & interface
- Absolute Encoder Communication interface = Endat01
Encoder Performance Parameters
- Absolute Encoder - Singleturn or multiturn version = Multiturn
- Absolute Encoder - Number of steps per revolution = 8192 (13 bit)
- Absolute Encoder Number of revolutions = 4096 (12 bit)
Absolute Encoder Programmable/configurable = NOT : Programmable/configurable
Encoder's Electrical Signal output connection - for Wiring to Upper Level Control PLC| CNC\ DRIVE
- Direction of Connection = Universal
- Connection Type Detail = PCB Connector 12 PIn
How Encoder body is Mouted ? Mouting Flange Design Data:
Details
