KI-3015LFPKG/SS-000-K
NO NC Programmable
3-15mm sensing
10-55v DC
250mA

IFM sensor KI3015LFPKG | KI-3015LFPKG/SS-000-K Capacitive sensor

$160.00
Skip to product information
KI-3015LFPKG/SS-000-K
NO NC Programmable
3-15mm sensing
10-55v DC
250mA
Make an Offer
Have a price in mind?

Send us your offer and quantity. We’ll review it and contact you if we can accept it or propose our best price.

Submitting an offer does not create an order. Your offer is subject to our acceptance and confirmation.
  • Ready Stock | Ship Worldwide
  •  Shipping Lead time 1-2 Days |Same day Emergency Rush Despatch Available upon Request.
  •  Rush Orders can be Collected from our Store after 4 Hours of Order | Payment Confirmation

IFM sensor KI3015LFPKG | KI-3015LFPKG/SS-000-K Capacitive sensor

$160.00
Taxes included. Shipping calculated at checkout.
  • Capacitive Sensor IFM
  • KI-3015 L FPKG/SS-000-K
  • K1-3015 L FPKG/SS-000-K
  • K13015LFPKGSS000K
  • KI-3015LFPKG/SS-000-K - NO NC Programmable
    3-15mm sensing
  • KI-3015
  •  KI3015LFPKGSS000K

Ready Stock Capacitive sensor IFM sensor KI-3015LFPKG/SS-000-K

KI5038
Capacitive sensor
KI-3015-FPKG/NI/SS-000-K

Product characteristics
Electrical design PNP
Output function normally open / normally closed; (selectable)
Sensing range [mm] 15
Housing threaded type
Dimensions [mm] M30 x 1.5 / L = 92
Electrical data
Operating voltage [V] 10...36 DC
Current consumption [mA] 13; (24 V)
Protection class III
Reverse polarity protection yes
Outputs
Electrical design PNP
Output function normally open / normally closed; (selectable)
Max. voltage drop switching
output DC [V] 2.5
Permanent current rating of
switching output DC [mA] 250
Switching frequency DC [Hz] 40
Short-circuit proof yes
Overload protection yes
Detection zone
Sensing range [mm] 15
Real sensing range Sr [mm] 15 ± 10 %
Operating distance [mm] 0...12.1
Accuracy / deviations
Correction factor glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2
Hysteresis [% of Sr] 1...15
Switch point drift [% of Sr] -15...15

Ships from DUBAI

Ready Stock - Collect from Ajman store today

Sold by Ajman FET [ Established 2003 ]

Worldwide Shiping
