IW5030, Inductive sensor, IW-3008-ANOG, 1W5030, IFM , NPN , NO , 8mm Rectangular
$280.00
Taxes included.
Shipping calculated at checkout.
You Are Welcome to use your OWN COURIER Account for Shipping.
Please Choose: In Store PICKUP option (instead of Ship) at Checkout/Payment Screen.
You Pay zero Shipping & You can Arrrange pickup via your DHL/ FEDEX/ UPS account.
Condition: New surplus / new old stock. SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: IFM
- Sensor Type: Inductive Proximity SensorInductive Sensor
- Sensor Dimensions: 60x36x10mm
- Sensor Range : 8 mm
- Product Condition New in Factory Sealed Packet:
Authorization status : Independent reseller
Manufacturer warranty status : Not represented as included
SpareFaber warranty : One-year limited seller warranty
IW5030, 10mm thick, 8mm Sensing dist. Inductive sensor, NPN, NO output, non-flush mountable,Rectangular secion. part number: IW-3008-ANOG
| Electrical design | NPN |
| Output function | normally open |
| Sensing range[mm] | 8 |
| Housing | rectangular |
| Dimensions[mm] | 60 x 36 x 10 |
Electrical data
| Operating voltage[V] | 10...36 DC |
| Current consumption[mA] | 15; (24 V) |
| Protection class | II |
| Reverse polarity protection | no |
Outputs
| Electrical design | NPN |
| Output function | normally open |
| Max. voltage drop switching output DC[V] | 1 |
| Permanent current rating of switching output DC[mA] | 250 |
| Switching frequency DC[Hz] | 120 |
| Short-circuit protection | no |
| Overload protection | no |
Detection zone
| Sensing range[mm] | 8 |
| Real sensing range Sr[mm] | 8 ± 10 % |
| Operating distance[mm] | 0...6.5 |
Accuracy / deviations
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2 |
| Hysteresis[% of Sr] | 1...15 |
| Switch point drift[% of Sr] | -10...10 |
Operating conditions
| Ambient temperature[°C] | -25...80 |
| Protection | IP 67 |
Tests / approvals
| EMC |
|
||||
| MTTF[years] | 1745 |
Mechanical data
| Housing | rectangular |
| Mounting | non-flush mountable |
| Dimensions[mm] | 60 x 36 x 10 |
| Materials | housing: PBT |
Displays / operating elements
| Display |
|
Remarks
| Pack quantity | 1 pcs. |
Electrical connection
| Cable | 20 m, PVC; 3 x 0.14 mm² |
- MPN : IW5030
- Manufacturer indent Nr. : IW5030IW3008-ANOG
- Manufacturer Product number : IW 5030
- Alternative ways of identifying | Part Numbers | Compatible Parts :
- Typographic Errors in MPN | Mistakenly Known as :
