Piab 0104274 | DS23 2425 SD | 01.04.640 | Solenoid valve DS 23 for control ON/OFF
$290.00
Skip to product information
- Ready Stock | Ship Worldwide
- Rush Orders can be Collected from our Store after 4 Hours of Order Confirmation
- We ship Same day if Order is confirmed before 2 PM on Weekdays
Piab 0104274 | DS23 2425 SD | 01.04.640 | Solenoid valve DS 23 for control ON/OFF
$290.00
Taxes included.
Shipping calculated at checkout.
SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: DS232425SD
- Manufacturer Alternative MPN ; DS23-2425-S-D
- Manufacturer Id Nr. DS23 2425 SD | 01.04.640
Piab, DS23-2425-S-D, Solenoid Valve 01.04.640
Item number: 0104274
Solenoid valve DS 23 for control ON/OFF
Choose between solenoid, electrically or vacuum-controlled valves. The vacuum controlled valve (Vacustat) shuts off the flow of compressed air to the pump when the pre-set level is reached, and consequently the consumption of compressed air is minimised.
Features
-
Electric 3/2 valve with manual override.
-
Quick and easy mounting with push-in connections.
-
Body with 3 M5 ports.
-
Suitable for compressed air, filtration 40µ.
General
Item number : 0104274
Item number (US): 01.04.274
Material : Al, CuZn, Nitrile (NBR), Nickel, POM, SS
Weight, min.: 100 g
Temperature: -18 - 50 °C
Status
Taric code: 85369095
Electrical data
Current, consumption: 100 mA
Display : LED indicator
Load time rating : 100 %
Safety classification : IP65
Voltage : 24 (22-28) VDC
Dimension
Height: 57.3 mm
Length : 15.9 mm
Width: 49.7 mm
Performance
Feed pressure : 0.2 - 0.6 MPa
Pneumatic data
Flow (@ P1=6 bar and ∆p=1 bar) 1.3 Nl/s
Life span : 100000000 cycles
Valve function : NC
- Product Condition Opened original packaging:
Authorization status : Independent reseller
Manufacturer warranty status : Not represented as included
SpareFaber warranty : One-year limited seller warranty
Packaging condition :
- Manufacturer indent Nr.0104640
- Alternative ways of identifying | Part Numbers | Compatible Parts
- Typographic Errors in MPN | Mistakenly Known as
EMERGENCY BREAKDOWN ? Need it Right away ( After Office hours?) .. No Problem | Can be arranged. Send us a Message.
