- Manufacturer Part Number: PSSu E F 4DI
- Manufacturer Alternative MPN ; Product ID: 312200
- Manufacturer Id Nr. PSSu
Pilz 312200 IO Module for PSSu Controller, 4 Input, 2 Test Pulse Output, 24 VDC, PSSu Series
MFR Part #: 312200 | RS Stock Number: 72232734
PSSu E F 4DI
Product ID: 312200
PSSu, electronic module, failsafe, digital inputs and outputs, 4 inputs, 2 test pulse outputs 0.25 A.
Technical data
Inputs
| Number of digital inputs | 4 |
| DC voltage at input | 24 V DC |
| Potential isolation inputs | ja |
Test clock outputs
| Number of test pulse outputs | 2 |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 60068-2-78 EN 60068-2-14 |
| Ambient temperature standard | EN 60068-2-14 |
| Ambient temperature | 0 |
| Storage temperature standard | EN 60068-2-1/-2 |
| Climatic suitability standard | EN 60068-2-78 |
| Humidity rating | P_FEUCHTE_WERT_93 % r. F. bei 40 °C |
| Condensation permitted? | unzulässig |
| Perm. operating height ASL | 2000 m |
| EMC to standard ... | EN 12015 EN 12016 EN 61000-6-2 EN 61000-6-4 EN 61131-2 (Zone B) |
| Vibration to standard ... | EN 60068-2-6 |
| Acc. shock to standard1 | 150 m/s² |
| Acc. shock to standard2 | |
| Clearance & creepage dist. to | EN 61131-2 |
| Overvoltage category | II |
| Pollution degree clear.&creep. | 2 |
| Protection type standard | EN 60529 |
| Protection type, mounting | IP54 |
| Protection type, housing | IP20 |
| Terminal protection type | IP20 |
Mechanical data
| Housing material lower section | PC |
| Housing material front plate | P_GEHAEUSE_MAT_F_PC |
| Housing material code | PA |
| Terminal style | steckbar |
| Height dimension | 76 |
| Width dimension | 12.6 |
| Depth dimension | 60.2 |
| Net weight | 35 |
| Gross weight | 44 |
| Name of coding element | D |
| Colour of coding element | gelb |
- Manufacturer indent Nr.PSSuEF4DI
