Zero-Max C216P 10mmx10mmx37L Double Disc-Control-Flex Clamp Hub Couplings
$85.00
Taxes included.
Shipping calculated at checkout.
Condition: New surplus / new old stock. SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: C216P 10mmx10mm
- Manufacturer Alternative MPN ; C216P 10mmx10mmx37.6mm Long
- Manufacturer Id Nr. C216P 10x10mm
C216P ZeroMax Double Disc Control Flex Coupling Bore:10mmxBore:10mm | L=37.6mm
- Product Name: Double Disc, Clamp Hub - 0.750" (20mm) Max Bore
- Model: C216 P
- Max. Continuous Torque : 57 in-lbs
- Max Peak Torque ; 81 in-lbs
- Maximum Bore 0.750 inches Or 20 mm
C216-P Double Disc Control Flex Couplings
| Part Number | C216P | C216P |
| Max Continuous Torque : | 6.44 Nm | 57 in-lbs |
| Max Peak Torque : | 9.15 Nm | 81 in-lbs |
| Minimum Bore : | 4 mm | 0.125 inches |
| Maximum Bore : | 20 mm | 0.750 inches |
| Maximum Speed: | 7,000 RPM | 7,000 RPM |
| Max Parallel Misalignment : | 0.5 mm | 0.019 inches |
| Max Angular Misalignment: | 1.0° | 1.0° |
| Maximum Axial Misalignment : | 0.4 mm | 0.014 inches |
| Torsional Stiffness : | 203 Nm/rad | 31.3 In-lbs/degree |
| Net Weight : | 0.066 kg | 0.145 lbs |
| Inertia (WK²) : | 0.114 kg-cm² | 0.039 lb-in² |
| Outside Diameter (D2) : | 37.0 mm | 1.457 inches |
| Overall Length (L) : | 37.6 mm | 1.48 inches |
| Hub Length (L1) : | 10.0 mm | 0.394 inches |
| Distance Between Shaft Ends (L2) : | 17.5 mm | 0.69 Inches |
| Inside Diameter of Disc (D4) : | 14.2 mm | 0.56 inches |
