Fail-safe inductive sensor GM505S | GIMC-4035-US
$130.00
Taxes included.
Shipping calculated at checkout.
Condition: New surplus / new old stock. SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: GM 505S
- Manufacturer Alternative MPN ; GIMC-4035-US
- Manufacturer Id Nr. GM 5O5S
Fail-safe inductive sensor GM505S
GIMC-4035-US
For ensuring machine safety
Certified to the following standards: EN 60947-5-3, IEC 61508 and ISO 13849
No special actuator for electronic fail-safe sensors required
Direct connection to safe ifm relays
Series connection of sensors possible
Product characteristics
| Output function | clock signal |
| Enable zone[mm] | 10...20 |
| Housing | rectangular |
| Dimensions[mm] | 40 x 40 x 66 |
Application
| Special feature | Gold-plated contacts |
| Type of operation | continuous operation (maintenance-free) |
| Safety-related sub-function | safe state when undamped correctly (s > sAs (sar)) |
| Application | Industrial applications / factory automation |
Electrical data
| Operating voltage[V] | 19.2...30 DC |
| Rated insulation voltage[V] | 30 |
| Current consumption[mA] | < 15 |
| Protection class | III |
| Reverse polarity protection | yes |
| Max. power-on delay time[ms] | 5000 |
Inputs
| Max. input capacitance Ci_max[nF] | 2 |
Outputs
| Output function | clock signal |
| Output data | Interface type B |
| Short-circuit protection | yes |
| Max. capacitive load CL_max[nF] | 20 |
Detection zone
| Enable zone[mm] | 10...20 |
| Safe switch-off distance s(ar)[mm] | 35 |
Response times
| Response time to safety request[ms] | 20 |
| Response time when approaching the enable zone[ms] | 200; (typical 100) |
Operating conditions
| Applications | class C to EN 60654-1 sheltered locations | |
| Ambient temperature[°C] | -25...70 | |
| Note on ambient temperature |
|
|
| Ambient temperature[°C] | 10...40 | |
| Note on ambient temperature |
|
|
| Rate of temperature change[K/min] | 0.5 | |
| Max. relative air humidity[%] | briefly: 5...95 %; permanent: 5...70 % | |
| Air pressure[kPa] | 80...106 | |
| Ionising radiation | not permissible | |
| Salt spray | no | |
| Protection | IP 65; IP 67; (to EN 60529) |
