Pepperl Fuchs 106623 NCN30+U1+N0,Normally Closed, Output type: NAMUR, 30mm
$280.00
Skip to product information
- Ready Stock | Ship Worldwide
- Rush Orders can be Collected from our Store after 4 Hours of Order Confirmation
- We ship Same day if Order is confirmed before 2 PM on Weekdays
Pepperl Fuchs 106623 NCN30+U1+N0,Normally Closed, Output type: NAMUR, 30mm
$280.00
Taxes included.
Shipping calculated at checkout.
Condition: New surplus / new old stock. SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: Pepperl + Fuchs
- Sensor Type: Block | Cube Housing - Rectangular Square- Inductive Sensor ( Limit Switch Style)Inductive Sensor
- Sensor Dimensions: 40 x 40 x 120mm
- Sensor Range : Sensing range [mm] 30 | non-flush
- Product Condition Opened original packaging:
Authorization status : Independent reseller
Manufacturer warranty status : Not represented as included
SpareFaber warranty : One-year limited seller warranty
NCN30+U1+N0, 106623, Normally Closed, Output type: NAMUR, Rated operating distance 30mm, Non Flush, 40x40x118
General specifications
Switching function Normally closed (NC)
Output type NAMUR
Rated operating distance sn 30 mm
Installation non-flush
Assured operating distance sa 0 ... 24.3 mm
Actual operating distance sr 27 ... 33 mm typ.
Reduction factor rAl 0.45
Reduction factor rCu 0.42
Reduction factor r304 0.79
Output type 2-wireNominal ratings
Installation conditions
A 10 mm
Nominal voltage Uo 8 V
Switching frequency f 0 ... 150 Hz
Hysteresis H 1 ... 15 typ. 5 %
Reverse polarity protection reverse polarity protected
Short-circuit protection yes
Current consumption
Measuring plate not detected min. 3 mA
Measuring plate detected ≤ 1 mA
Switching state indicator LED, yellow
Functional safety related parameters
MTTFd 3335 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
Compliance with standards and directives
Standard conformity
NAMUR EN 60947-5-6:2000
IEC 60947-5-6:1999
Electromagnetic compatibility NE 21:2007
Standards EN 60947-5-2:2007
EN 60947-5-2/A1:2012
IEC 60947-5-2:2007
IEC 60947-5-2 AMD 1:2012
Approvals and certificates
FM approval
Control drawing 116-0165
UL approval cULus Listed, General Purpose
CSA approval cCSAus Listed, General Purpose
CCC approval CCC approval / marking not required for products rated ≤36 V
Ambient conditions
Ambient temperature -25 ... 100 °C (-13 ... 212 °F)
Storage temperature -40 ... 100 °C (-40 ... 212 °F)
Mechanical specifications
Connection type screw terminals
Information for connection A maximum of two conductors with the same core cross section may be mounted on
one terminal connection!
tightening torque 1.2 Nm + 10 %
Core cross-section up to 2.5 mm2
Minimum core cross-section without wire end ferrule 0.5 mm2
, with connector sleeves 0.34 mm2
Maximum core cross-section without wire end ferrule 2.5 mm2
, with connector sleeves 1.5 mm2
Connection (system side) screw terminals , M20 x 1.5 cable gland , usable thread length 9.1 mm , screw-in depth
max. 9.1 mm
Housing material PBT
Sensing face PBT
Degree of protection IP68
Note Tightening torque: 1.8 Nm (housing)
General information
Use in the hazardous area see instruction manuals
- MPN : NCN30+U1+N0
- Manufacturer indent Nr. : NCN30+U1+N0NCN30U1N0
- Manufacturer Product number : NCN30+U1+NO
- Alternative ways of identifying | Part Numbers | Compatible Parts :
- Typographic Errors in MPN | Mistakenly Known as :
