Ultrasonic Sensor UZDK 30P6103 Article no.: 10130587 sensor with two switching point
$850.00
Taxes included.
Shipping calculated at checkout.
SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: UZDK 30P6103
- Manufacturer Alternative MPN ; Article no.: 10130587
- Manufacturer Id Nr. UZDK30P6103
Ultrasonic Sensor UZDK 30P6103 | UZDK30P6103, Article no.: 101 30 587, sensor with two switching point , Ultrasonic proximity sensor
Ultrasonic 2 point proximity switch
100 … 1000 mm
PNP make function (NO)
Teach-in
cable, 2 m
-10 … 60 °C
IP 67
General data
Special type 2 point proximity switch
Scanning range Sd : 100 … 1000 mm
Scanning range far limit Sde : 100 … 1000 mm
Hysteresis typ. : 4 % Sde
Repeat accuracy : 0.5 mm
Temperature drift : < 2 % Sde
Response time ton : < 40 ms
Release time toff : < 40 ms
Sonic frequency : 240 kHz
Adjustment : Teach-in
Alignment aid : Target indication flashing
Output indicator : Green / yellow LED
Electrical data :
Voltage supply range +Vs : 12 … 30 VDC
Current consumption max. (no load) : 40 mA
Output circuit : PNP make function (NO)
Output current : 200 mA
Voltage drop Vd : <2 VDC
Residual ripple : < 10 % Vs
Short circuit protection : Yes
Reverse polarity protection : Yes
Mechanical data
Design : Rectangular
Housing material : Polyester / die-cast zinc
Width / diameter : 30 mm
Height / length : 65 mm
Depth : 31 mm
Connection types : Cable, L=2 m
Ambient conditions :
Operating temperature -10 … +60 °C
Protection class : IP 67
- Product Condition New in Factory Sealed Packet:
Authorization status : Independent reseller
Manufacturer warranty status : Not represented as included
SpareFaber warranty : One-year limited seller warranty
Packaging condition :
- Manufacturer indent Nr.UZDK-30P6103
- Alternative ways of identifying | Part Numbers | Compatible Parts
- Typographic Errors in MPN | Mistakenly Known as
