DriveCliq- Drive Component Link with IQ - Cables
DRIVE-CLiQ (Drive Component Link with IQ) is a high-speed internal communication interface created by Siemens for the SINAMICS S120 and related drive families. It links control units, line modules, motor modules, motors, and encoders using a simple point-to-point connection.
Learn from Heidenhain about encoders:
Key Features
Auto-Detection: The control unit automatically finds and recognizes all connected hardware when powered on.
Standardized Parts: Uses uniform cables and connectors to reduce spare parts and storage needs.
Clear Diagnostics: Allows users to check status, fix errors, and service right down to the individual component level.
Power Supply: Each port provides 24 V and 450 mA to run attached encoders or sensors.
What It Connects
Control units to power blocks
Motors with built-in digital nameplates
External or cabinet-mounted encoder sensor modules
Terminal input/output expansion modules
