Heidenhain_ERN 1387.001-2048, Id. Nr. 312 215-14; ~1,1Vss, 5v+-5%
Sale price
$663.00
Regular price
$780.00
Skip to product information
- Ready Stock | Ship Worldwide
- Shipping Lead time 1-2 Days |Same day Emergency Rush Despatch Available upon Request.
- Rush Orders can be Collected from our Store after 4 Hours of Order | Payment Confirmation
Heidenhain_ERN 1387.001-2048, Id. Nr. 312 215-14; ~1,1Vss, 5v+-5%
Sale price
$663.00
Regular price
$780.00
Taxes included.
Shipping calculated at checkout.
You Are Welcome to use your OWN COURIER Account for Shipping.
Please Choose: In Store PICKUP option (instead of Ship) at Checkout/Payment Screen.
You Pay zero Shipping & You can Arrrange pickup via your DHL/ FEDEX/ UPS account.
Condition: New surplus / new old stock. SpareFaber is an independent reseller and is not an authorized distributor of this brand. Manufacturer warranty is not represented as included. Any stated warranty is provided solely by SpareFaber under our Limited Seller Warranty terms.
- Manufacturer Part Number: 312 215-14
- Encoder Type: Incremental encoder
- Supply voltage 5 V
- Encoder ID. NR.ERN1387.001-2048
- Encoder SIgnal | 2048 | 1 Vpp sin/cos | Ø 58 mm | PCB Connector 12 PIn
Ready Stock ERN 1387.001-2048, Id. Nr. 312 215-14; ~1,1Vss, 5v+-5%
ERN1387.001-2048
Id. Nr. 312215-14; ~1,1Vss, 5v+-5%
Incremental rotary encoder with integral bearing for mounting by stator coupling
Line count: 2048
Add. circular-scale track: 1 sine and 1 cosine signal/revolution
Output signal: ~1Vpp
Cutoff frequency (-3dB): 210.00 kHz
Power supply: 5V (+-5%)
Coupling version: expanding ring coupling for mating diameter 65mm
Shaft: taper shaft 1:10, functional diameter 9.25mm, back-off thread M10 and M6
Degree of protection: IP 40 (EN 60529)
Operating temperature: -40/+120 °C
Electrical connection: plug connector, straight, double-row, 14-pin, with locking mechanism and walls
Pin configuration: D319274
Connecting direction: Cable outlet for axial and radial use
Encoder Type:
Salient | Special features of Encoder:
Encoder mechanical Design
- Increental Encoder Mechanical Design Taper Shaft Heidenhain
- Incremental Encoder Construction size (flange) Ø 58 mm
- Incremental Encoder Shaft diameter Shaft: 1:10 tapered shaft, functional diameter 9.25 mm, pull-out threads M10 and M6.
Encoder Signal Interface | Communication
- Incremental Encoder Communication Interface detail 1 Vpp sin/cos
Performance Data:
Incremental encoder PPR | Impulse | Pulses per revolution2048
- incremental Encoder Range of pulses per revolution1 … 2048 programmable
- Signal Details:
Connection Details of encoder
- Connection type (Detail)PCB Connector 12 PIn
- Direction of connection
Mounting Arrangement for Encoder Body
- Check Datasheet or Contact us
- Manufacturer Alternative MPNERN 1387.001-2048
- Manufacturer indent Nr.312215-14
- 1 Manufacturer Part Number (MPN) 312 215-14
- Alternative ways of identifying | Part Numbers | Compatible Parts
- Typographic Errors in MPN | Mistakenly Known as
